Millimeter Wave Solutions
DC to 67GHz 1.85mm Female to 1.85mm Female Precision Adapter
Professional grade 1.85mm precision adapter optimized for V-band and millimeter-wave applications. Engineered to ensure minimal signal reflection and industry-leading performance stability up to 67 GHz.
Electrical Specifications
| Frequency Range | DC to 67 GHz |
| V.S.W.R | ≤ 1.30 : 1 |
| Impedance | 50 Ohm |
| Insulation Resistance | ≥ 5000 MΩ |
| Dielectric Withstand Voltage | 1000 V |
Mechanical Specifications
| Model Name | 1.85-KKG |
| Connector Interface | 1.85mm Female to 1.85mm Female |
| Durability | 500 Cycles |
| Operating Temperature | -55°C to +165°C |
| Manufacturing Origin | Taiwan |
Tactical Engineering Features
Millimeter-Wave Excellence
Designed for ultra-high frequencies up to 67 GHz, supporting 6G research, automotive radar testing, and high-capacity backhaul systems.
Extreme Thermal Stability
Specifically engineered to maintain signal integrity between -55°C and +165°C, suitable for aerospace and environmental chamber testing.
High Durability Standard
Exceeds 500 mating cycles without performance degradation, ensuring long-term reliability in mission-critical laboratory environments.
