Construction :
Inner conductor
Plain copper
7 x 0.72 mm
Dielectric
Low density PE
Φ7.25 ± 0.18 mm
Outer conductor (shield)
Plain copper
192 x 0.2 mm
Shield coverage
98%
Sheath
PVC or...
UP to 3GHz
Impedance: 53 Ohm
Capacitance: 83 pF/m
Conductor: Bare Copper Wire (1/1.02mm)
Shield Coverage: 98%
Minimum Bend Radius: min. 20mm
Diameter
Material
Conductor
1.02 mm
Bare Copper Wire
Insulation
2.9 mm
Foam...
Construction :
Inner conductor
Plain copper
Φ0.80 ± 0.025 mm
Dielectric
Low density PE
Φ2.95 ± 0.10 mm
Outer conductor
Tinned copper
112 x 0.13 mm
Shield coverage
95%
Sheath
PVC or LSZH
Φ5.00...
Construction :
Inner conductor
Plain copper
7 x 0.75 mm
Dielectric
Low density PE
Φ7.25 ± 0.18 mm
Outer conductor
Plain copper
192 x 0.18 mm
Shield coverage
97%
Sheath
PVC or LSZH
Φ10.3...
Construction :
Inner conductor
Silver plated copper
7 x 0.75 mm
Dielectric
Low density PE
Φ7.25 ± 0.18 mm
Outer conductor(shield 1)
Silver plated copper
144 x 0.16 mm
Shield...
Construction :
Inner conductor
Silver plated copper
Φ0.90 ± 0.025 mm
Dielectric
Low density PE
Φ2.95 ± 0.10 mm
Outer conductor(shield 1)
Silver plated copper
112 x 0.13 mm
Shield...
