1710MHz to 1880MHz 14dbi Panel Directional Outdoor Antenna1710MHz to 1880MHz 14dbi Panel Directional Outdoor Antenna1710MHz to 1880MHz 14dbi Panel Directional Outdoor Antenna

Model No: PA-171814-NF

  • Dimension : L275xW275xD45mm
  • Weight : 0.8 KG
  • Connector : N-Female
  • Beam-width : Horz.40 deg Vert.36 deg
INQUIRY

Applications

  • 1710MHz - 1880MHz Band
  • 14dbi Panel Directional Outdoor Antenna for Directional Multipoint application
  • Point to Point Bridge
  • Public Wireless Hotspot
  • RFID
  • Wireless Video Systems

Features

  • Superior performance
  • Lightweight
  • All-weather operation
  • DC Short lightning protection
  • Vertical Installation
  • Including tilt and swivel mast mounting kit

Frequency Range

1710MHz - 1880MHz

V.S.W.R (MAX)

1.3 :1

Antenna Type

Patch Type

RadiationDirectional

Gain (Avg)

14 dBi

Polarization

Vertical or Horizontal

Maximum Power

5 Watts

Vertical Beam-width

36 Deg

Horizontal Beam-width

40 Deg

F /BGreater than 20 dB

Impedance

50 Ohm

Antenna Design

2x2 Patch Array

Internal Material

FR4(Taiwan)

Connector

N-Female

Length x Width(MAX)

275 x 275mm

Diameter (MAX)

45mm

Antenna Weight (G.W)

500 g

Accessories (G.W)

300 g

ApplicationIndoor / Outdoor

Radome Material

White ABS

Mount StylePole Mount / Wall Mount

Parts Material

Aluminum

MountingStainless Steel
Mount Adjustment0-30deg

Wind Survival

Greater than 150MPH

Storage Temperature-20 to +80
Operating Temperature-20 to +60
Operating Humidity10%~80% non-condensing
Storage Humidity

5%~80% non-condensing

Safety, Emission and other

CE, FCC, RoHS
