2.3GHz-2.7GHz 5dBi Outdoor Base Station OMNI Directional Antenna2.3GHz-2.7GHz 5dBi Outdoor Base Station OMNI Directional Antenna2.3GHz-2.7GHz 5dBi Outdoor Base Station OMNI Directional Antenna

Model No: OA-232705-NF

  • Dimensions: 445x70x50mm
  • Weight: 370g
  • Connector: N-Female
  • Beam-width: Horz.360 deg Vert.19 deg
INQUIRY

Applications:

  • 2.3GHz-2.7GHz 5dbi

  • IEEE 802.11b,802.11g,802.11b/g,802.11n ,802.16x ,802.20x Wireless Lan

  • Omni Directional Multipoint applications

  • Point to Multipoint

  • Public Wireless Hotspot

  • WiFi,WiMax

  • Wireless Video Systems

Features:

  • Superior Performance

  • Lightweight

  • Good appearance design

  • DC Short lightning protection

  • Narrow base station descent

  • Behind and support are made of aluminum

  • Outdoor antenna for public hotspots

  • Includes tilt and swivel mast mount brackets

  • RoHS Compliant

Frequency Range

2300MHz - 2700MHz

V.S.W.R (MAX)

2.0 :1

Antenna Type

Collinear

Radiation Omni Directional

Gain (MAX)

5 dBi

Polarization

Vertical

Maximum Power

200 Watts

Vertical Beam-width

19 Deg

Horizontal Beam-width

360 Deg

Impedance

50 Ohm

Antenna Design

Dipole Array

Internal Material

Copper

Connector

N-Female

Length (MAX)

445 mm

Diameter (MAX)

70 x 50mm

Antenna Weight (G.W)

370 g

Accessories (G.W)

50 g

Application Indoor / Outdoor

Radom Material

White Fiberglass

Parts Material

Aluminum

Mount Style Pole Mount/Well Mount
Mounting Stainless Steel

Wind Survival

Greater than 150MPH

Storage Temperature

-40to +80

Operating Temperature -40to +60
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing

Safety, Emission and other

CF, FCC, RoHS
