2.3GHz to 2.7GHz 10dBi Outdoor Base Station OMNI Directional Antenna2.3GHz to 2.7GHz 10dBi Outdoor Base Station OMNI Directional Antenna2.3GHz to 2.7GHz 10dBi Outdoor Base Station OMNI Directional Antenna

Model No: OA-232710-NF

  • Dimension : 1050x120x80mm
  • Weight : 1200g
  • Connector : N-Female
  • Beam-width : Horz.360 deg Vert.9 deg
INQUIRY

Applications:

  • 2.3GHz-2.7GHz band
  • IEEE 802.11b,802.11g,802.11b/g,802.11n ,802.16x ,802.20x Wireless Lan
  • Omni Directional Multipoint applications
  • Point to Multipoint
  • Public Wireless Hotspot
  • WiFi, WiMax
  • Wireless Video Systems

Features:

  • Superior performance
  • Lightweight
  • Good appearance design
  • DC Short lightning protection
  • Collinear Vertical Polarization Installation
  • Behind and support is an aluminum
  • Outdoor antenna for public hotspot
  • Includes tilt and swivel mast mounting kit
  • RoHS Compliant

Frequency Range

2300MHz - 2700MHz

V.S.W.R (MAX)

1.3 :1

Antenna Type

Collinear

Radiation Omni Directional

Gain (MAX)

10 dBi

Polarization

Vertical

Maximum Power

200 Watts

Vertical Beam-width

9 Deg

Horizontal Beam-width

360 Deg

Impedance

50 Ohm

Antenna Design

Dipole Array

Internal Material

Copper

Connector

N-Female

Length (MAX)

1050 mm

Diameter (MAX)

120 x 80mm

Antenna Weight (G.W)

1070 g

Accessories (G.W)

130 g

Application Indoor / Outdoor

Radome Material

White Fiberglass

Parts Material

Aluminum

Mount Style 42 to 78mm Pole Mount  8mm Well Mount
Mounting Stainless Steel

Wind Survival

Greater than 150MPH

Storage Temperature

-20 to +80

Operating Temperature -20 to +60
Operating Humidity 10%~80% non-condensing
Storage Humidity 5%~80% non-condensing

Safety, Emission and other

RoHS
