Attenuation
-
Conductor
|
Frequency(MHz) |
30 |
50 |
150 |
220 |
450 |
900 |
1500 |
1800 |
2000 |
2500 |
5800 |
|
Attenuation(M/dB) |
0.044 |
0.057 |
0.099 |
0.12 |
0.173 |
0.248 |
0.324 |
0.356 |
0.377 |
0.424 |
0.668 |
|
Attenuation(ft/dB) |
0.013 |
0.017 |
0.03 |
0.037 |
0.053 |
0.076 |
0.099 |
0.109 |
0.115 |
0.129 |
0.204 |
|
Avg.Power(W) |
1490 |
1150 |
660 |
540 |
380 |
260 |
200 |
180 |
170 |
150 |
100 |
Max Cable Loss ={(Cable length x Frequency Attenuation)+ 0.4 }
| Part Designation | Material | Outer Diameter (mm) |
| Inner conductor | Solid Copper Wire | Nominal 1.42 |
| Insulation | Foam polyethylene | Nominal 3.81 |
| Shield | Aluminum/PE Tape | Nominal 3.92 |
| Outer conductor Single braid | Coverage 84%(Approx.) | Nominal 4.5 |
| Jacket | PE or Non-Lead PVC | Nominal 6.1 |
