Applications and Features
-
Electrical Specifications
-
Mechanical Specifications
Applications:
-
3.4GHz to 3.6GHz Band
-
IEEE 802.11x Wireless Lan
-
10dBi Omni Directional Multipoint applications
-
MMDS
-
Public Wireless Hotspot
-
WiMAX ,WiBro
-
Wireless Video Systems
Features:
-
Superior Performance
-
Lightweight
-
Good appearance designs
-
DC Short lightning protection
-
Antenna support is easily adjusted up and down
-
Behind and support are made of aluminum
-
Outdoor antenna for public spots
-
Includes tilt and swivel mast mount brackets
-
RoHS Compliant
|
Frequency Range |
3400MHz -3600MHz |
|---|---|
|
V.S.W.R (MAX) |
1.3 :1 |
|
Antenna Type |
Collinear |
| Radiation | Omni Directional |
|
Gain (MAX) |
10 dBi |
|
Polarization |
Vertical |
|
Maximum Power |
100 Watts |
|
Vertical Beam-width |
10 Deg |
|
Horizontal Beam-width |
360 Deg |
|
Impedance |
50 Ohm |
|
Antenna Design |
Dipole Array Dipole |
|
Internal Material |
Copper |
|
Connector |
N-Female |
|
Length (MAX) |
600 mm |
|---|---|
|
Diameter (MAX) |
70 x 55mm |
|
Antenna Weight (G.W) |
480 g |
|
Accessories (G.W) |
50 g |
| Application | Indoor / Outdoor |
|
Radome Material |
White Fiberglass |
|
Parts Material |
Aluminum |
| Mount Style | Pole Mount / Well Mount |
| 32 to 45mm Mounting | Stainless Steel U-Type Screw |
|
Wind Survival |
Greater than 150MPH |
|
Storage Temperature |
-20 to +80 |
| Operating Temperature | -20 to +60 |
| Operating Humidity | 10%~80% non-condensing |
| Storage Humidity | 5%~80% non-condensing |
|
Safety,Emission and other |
RoHS |
