Millimeter Wave RF Solutions
3.5mm Female to 3.5mm Female Precision Adapter (3.5-JJG)
High-precision millimeter wave adapter designed for DC to 33GHz applications, featuring superior VSWR performance and industrial-grade durability.
Electrical Specifications
| Frequency Range | DC – 33 GHz |
| VSWR (MAX) | ≤ 1.20 : 1 |
| Impedance | 50 Ω |
| Insulation Resistance | ≥ 5000 MΩ |
| Dielectric Withstand Voltage | 1000 V |
Mechanical & Environmental
| Model Name | 3.5-JJG (Female to Female) |
| Durability | 500 Cycles |
| Temperature Range | -55℃ ～ +165℃ |
Tactical Engineering Features
Precision Millimeter Wave
Engineered for DC-33GHz high-frequency testing and measurement, ensuring minimal signal reflection.
High-Grade Insulation
Features ≥5000MΩ insulation resistance and robust dielectric strength for mission-critical RF environments.
Extreme Durability
Built to withstand 500 mating cycles while maintaining electrical precision and mechanical integrity.
Wide Temperature Span
Stable operation across extreme thermal ranges from -55℃ up to +165℃, ideal for aerospace and industrial use.
