4.9 GHz to 6.2 GHz 5dbi Outdoor Super Mini Omni Directional Antenna (N-Male)4.9 GHz to 6.2 GHz 5dbi Outdoor Super Mini Omni Directional Antenna (N-Male)4.9 GHz to 6.2 GHz 5dbi Outdoor Super Mini Omni Directional Antenna (N-Male)

Model No: OI-496205-NM

  • Dimensions: 120x13mm
  • Weight: 45g
  • Connector: N-Male
  • Beam-width: Horz.360 deg Vert.21 deg
INQUIRY

Applications:

  • 4.9GHz-6.2GHz Band

  • IEEE 802.11 System

  • 5dBi Super Mini Omni Directional Multipoint applications

  • Point to Point Bridge / MMDS / Hotspot

  • Pubic Wireless

  • WiMAX,WLAN,WiFi,802.11a

  • Wireless Video Systems

Features:

  • Superior Performance

  • Lightweight

  • Good appearance design

  • DC Short lightning protection

  • Narrow base station descent

  • Behind and support are made of aluminum

  • Outdoor antenna for public spots

  • Includes tilt and swivel mast mount brackets

  • RoHS Compliant

Frequency Range

4900MHz- 6200MHz

V.S.W.R (MAX)

1.5 :1

Antenna Type

Collinear

Radiation Mini Omni Directional

Gain

5 dBi

Polarization

Vertical

Maximum Power

5 Watts

Vertical Beam-width

21 Deg

Horizontal Beam-width

360 Deg

Impedance

50 Ohm

Antenna Design

Dipole Array

Internal Material

PCB+Spring

Connector

N-Male

Length (MAX)

120 mm

Diameter (MAX)

20 mm

Antenna Weight (G.W)

45 g

Application

Outdoor / Indoor

Radome Material

White Fiberglass

Parts Material

Aluminum

Wind Survival

Greater than 150MPH

Storage Temperature

-40 to +80
Operating Temperature  -40 to +60

Operating Humidity

10%~90% non-condensing
Storage Humidity

5%~90% non-condensing

Safety, Emission and other

 RoHS , CE, FCC, WEEE
