Descriptions
Precision Sub-Miniature Interconnects
SMA Male to SMA Female Precision Adapter (SMA-JKG)
Professional grade straight SMA Male to SMA Female adapter engineered for high-performance signal transition. Delivering superior mechanical durability and consistent signal integrity for laboratory testing and industrial wireless systems up to 6 GHz.
Electrical Specifications
| Frequency Range | DC – 6 GHz |
| V.S.W.R (MAX) | ≤ 1.20 : 1 |
| Impedance | 50 Ω |
| Insulation Resistance | ≥ 5000 MΩ |
| Dielectric Withstand Voltage | 1000 V |
Mechanical & Environmental
| Model Name | SMA-JKG |
| Connector Interface | SMA Male to SMA Female |
| Durability | 500 Mating Cycles |
| Temperature Range | -55℃ ～ +165℃ |
Engineering Core Features
High-Precision Signal Integrity
Precision-machined interface designed to maintain strict 50-ohm impedance matching and minimize signal reflection (VSWR ≤ 1.20) across broadband wireless frequencies.
Industrial Grade Build
Constructed with premium materials and manufactured in Taiwan to ensure high mechanical strength and reliable electrical contact through 500 mating cycles.
Extreme Thermal Tolerance
Operates reliably across a vast thermal span (-55℃ to +165℃), ideal for aerospace, defense, and high-stress environmental testing chambers.
Mission-Critical Reliability
Ensures seamless in-series coupling for telecommunications, Wi-Fi infrastructure, and professional RF measurement chains.
