2.5GHz-2.7GHz 4dBi Outdoor OMNI Directional Antenna2.5GHz-2.7GHz 4dBi Outdoor OMNI Directional Antenna2.5GHz-2.7GHz 4dBi Outdoor OMNI Directional Antenna

Model No: OA-252704-NF

  • Dimensions: 280x70x50mm
  • Weight: 260g
  • Connector: N-Female
  • Beam-width: Horz.360 Deg Vert.50 Deg
INQUIRY

Applications:

  • 2.5GHz-2.7GHz Band ,2.6GHz Band

  • IEEE 802.11x Wireless Lan

  • 4dBi Omni Directional Multipoint applications

  • MMDS

  • Pubic Wireless Hotspot

  • WiMAX ,WiBro

  • Wireless Video Systems

Features:

  • Superior Performance

  • Lightweight

  • Good appearance design

  • DC Short lightning protection

  • Narrow base station descent

  • Behind and support are made of aluminum

  • Outdoor antenna for public hotspots

  • Includes tilt and swivel mast mount brackets

  • RoHS Compliant

Frequency Range

2500MHz - 2700MHz

V.S.W.R (MAX)

1.3 :1

Antenna Type

Collinear

Radiation Omni Directional

Gain (MAX)

4 dBi

Polarization

Vertical

Maximum Power

50 Watts

Vertical Beam-width

50 Deg

Horizontal Beam-width

360 Deg

Impedance

50 Ohm

Antenna Design

Dipole Array

Internal Material

Copper

Connector

N-Female

Length (MAX)

280mm

Diameter (MAX)

70 x 55mm

Antenna Weight (G.W)

210 g

Accessories (G.W)

50 g

Application Indoor / Outdoor

Radome Material

White Fiberglass

Parts Material

Aluminum

Mount Style Pole Mount / Well Mount
32 to 45mm Mounting Stainless Steel U-Type Screw

Wind Survival

Greater then 180MPH

Storage Temperature

-40 to +80

Operating Temperature -40 to +60
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing

Safety, Emission and other

RoHS, CE, FCC, WEEE
