Applications and Features
-
Electrical Specifications
-
Mechanical Specifications
Applications:
- 2.3GHz - 2.4GHz Band
- IEEE 802.11x Wireless Lan
- 12dBi Omni Directional Multipoint applications
- MMDS
- Pubic Wireless Hotspot
- WiMAX ,WiBro
- Wireless Video Systems
Features:
- Superior performance
- Lightweight
- Good appearance design
- DC Short lightning protection
- Collinear Vertical Polarization Installation
- Behind and support is an aluminum
- Outdoor antenna for public Hot spots
- Includes tilt and swivel mast mounting kit
- RoHS Compliant
|
Frequency Range |
2300MHz - 2400MHz |
|---|---|
|
V.S.W.R (MAX) |
1.3 :1 |
|
Antenna Type |
Collinear |
| Radiation | Omni Directional |
|
Gain (MAX) |
12 dBi |
|
Polarization |
Vertical |
|
Maximum Power |
50 Watts |
|
Vertical Beam-with |
6 Deg |
|
Horizontal Beam-with |
360 Deg |
|
Impedance |
50 Ohm |
|
Antenna Design |
Dipole Array |
|
Internal Material |
Copper |
|
Connector |
N-Female |
|
Length (MAX) |
1140 mm |
|---|---|
|
Diameter (MAX) |
70 x 50mm |
|
Antenna Weight (G.W) |
600 g |
|
Accessories (G.W) |
70 g |
| Application | Indoor / Outdoor |
|
Radome Material |
White Fiberglass |
|
Parts Material |
Aluminum |
| Mount Style | Pole Mount / Wall Mount |
| Mounting | Stainless Steel and Aluminum |
|
Wind Survival |
Greater than 150MPH |
|
Storage Temperature |
-40 to +80 |
| Operating Temperature | -40 to +60 |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
|
Safety, Emission and other |
CE, FCC, RoHS |
