Applications and Features
-
Electrical Specifications
-
Mechanical Specifications
Applications:
- 2.3GHz - 2.7GHz band
- IEEE 802.11b,802.11g,802.11b/g,802.11n ,802.16x ,802.20x Wireless Lan
- Omni Directional Multipoint applications
- Point to Multipoint
- Public Wireless Hotspot
- WiFi, WiMax
- Wireless Video Systems
Features:
- Superior performance
- Lightweight
- Good appearance design
- DC Short lightning protection
- Collinear Vertical Polarization Installation
- Behind and support is an aluminum
- Outdoor antenna for public hotspot
- Includes tilt and swivel mast mounting kit
- RoHS Compliant
|
Frequency Range |
2300MHz - 2700MHz |
|---|---|
|
VSWR (MAX) |
1.3 :1 |
|
Antenna Type |
Collinear |
| Radiation | Omni Directional |
|
Gain (MAX) |
12 dBi |
|
Polarization |
Vertical |
|
Maximum Power |
200 Watts |
|
Vertical Beam-width |
6 Degree |
|
Horizontal Beam-width |
360 Degree |
|
Impedance |
50 Ohm |
|
Antenna Design |
Dipole Array |
|
Internal Material |
Copper |
|
Connector |
N-Female |
|
Length (MAX) |
1350 mm |
|---|---|
|
Diameter (MAX) |
1095 x 70mm |
|
Antenna Weight (NW) |
1036.40 g |
|
Accessories (GW) |
89.27 g |
| Application | Indoor / Outdoor |
|
Radome Material |
White Fiberglass |
|
Parts Material |
Aluminum |
| Mount Style | 42 to 78mm Pole Mount 8mm Well Mount |
| Mounting | Stainless Steel |
|
Wind Survival |
Greater than 150MPH |
|
Storage Temperature |
-20 to +80 |
| Operating Temperature | -20 to +60 |
| Operating Humidity | 10%~80% non-condensing |
| Storage Humidity | 5%~80% non-condensing |
|
Safety, Emission and other |
RoHS |
