1080MHz to 1200MHz 14dBi Vertical or Horizontal Panel Directional Antenna1080MHz to 1200MHz 14dBi Vertical or Horizontal Panel Directional Antenna1080MHz to 1200MHz 14dBi Vertical or Horizontal Panel Directional Antenna

Model No: PA-111214-NF

  • Dimension : 375x375x35mm
  • Weight : 1.4 KG
  • Connector : N-Female
  • Beam-with : Horz.30 deg Vert.30 deg
INQUIRY

Applications:

  • 1080MHz to 1200MHz Band
  • Directional Multipoint applications
  • Point to Point Bridge / MMDS / Hotspot
  • Public Wireless
  • Wireless Video Systems

Features:

  • Superior Performance
  • Good appearance design
  • DC Short lightning protection
  • Support is up and down or so to adjust
  • Behind and support is made of aluminum
  • Outdoor antenna for public
  • Including tilt and swivel mast mounting kit
  • RoHS Compliant

Frequency Range

1080MHz to 1200MHz

V.S.W.R (MAX)

1.3 :1

Antenna Type

Patch Type

Radiation Directional

Gain (Avg)

14 dBi

Polarization

Vertical or Horizontal

Maximum Power

15 Watts

Vertical Beam-with

30 Deg

Horizontal Beam-with

30 Deg

F / B -25 dB

Impedance

50 Ohm

Antenna Design

Patch Array (2x2)

Internal Material

FR4(Taiwan)

Implant resistance DC Ground

Connector

N-Female

Length x Width(MAX)

375 x 375mm

Diameter (MAX)

35mm

Antenna Weight (G.W)

1050 g

Accessories (G.W)

300 g

Application Indoor / Outdoor

Radome Material

White ABS

Mount Style Pole Mount

Parts Material

Aluminum

Mounting Stainless Steel
Mount Adjustment +- 28deg

Wind Survival

Greater then 150MPH

Storage Temperature -20 to +80
Operating Temperature -20 to +60
Operating Humidity 10%~80% non-condensing
Storage Humidity

5%~80% non-condensing

Safety, Emission and other

CE, FCC, RoHS
