Applications and Features
-
Electrical Specs
-
Mechanical Specs
Applications:
-
5.15GHz-5.875GHz Band
-
IEEE 802.11a and 802.11n applications
-
12dBi Directional Multipoint applications
-
Point to Point Bridge / MMDS
-
Public Wireless
-
WiMAX, WiLAN, WiFi,802.11a
-
5.8GHz Wireless Video Systems
Features:
-
Superior Performance
-
Lightweight
-
Good appearance designs
-
DC Short lightning protection
-
Outdoor antenna for public
-
Includes tilt and swivel mast mount brackets
-
RoHS Compliant
| Frequency | 5125MHz - 5875MHz |
| V.S.W.R (MAX) | 2.0 :1 |
| Antenna Type | Patch Type |
| Radiation | +-45∘ |
| Gain | 12 dBi |
| Polarization | Vertical and Horizontal |
| Maximum Power | 25 Watts |
| Vertical Beam-width | -45: 18 deg
+45: 17 deg |
| Horizontal Beam-width |
+45: 67 Deg -45: 67 Deg |
| FBR | Greater than 18 dB |
| Impedance | 50 Ohm |
| Antenna Design | Patch Array |
| Internal Material | PTFE( Rogers PCB) |
| Connector | SMA-Female*2 |
|
Length x Width |
180 x 150mm |
|---|---|
|
Diameter |
25mm |
|
Antenna Weight |
220 g |
|
Accessories |
200 g |
| Application | Indoor / Outdoor |
|
Radome Material |
Gray ABS+UV |
| Mount Style | Pole Mount/ Wall Mount |
|
Parts Material |
Aluminum |
| Mounting | Stainless Steel |
| Mount Adjustment | 0-30deg |
|
Wind Survival |
Greater than 120MPH |
| Storage Temperature | -40 to +80 |
| Operating Temperature | -40 to +60 |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity |
5%~90% non-condensing |
|
Safety, Emission and other |
CE, FCC, RoHS |
