Applications:
5.15GHz-5.875GHz Band
IEEE 802.11 System
21dBi Directional Multipoint applications
Point to Point Bridge / MMDS
Public Wireless
WiMAX,WLAN,WiFi,802.11a
Wireless Video Systems
Features:
Superior Performance
Lightweight
Good appearance designs
DC Short lightning protection
Outdoor antenna for public hotspots
Includes tilt and swivel mast mount brackets
RoHS Compliant
Frequency Range |
5125MHz - 5875MHz |
---|---|
V.S.W.R (MAX) |
1.5 :1 |
Antenna Type |
Patch Type |
Radiation | Directional |
Gain |
21 dBi |
Polarization |
Vertical or Horizontal |
Maximum Power |
10 Watts |
Vertical Beam-with |
14 Deg |
Horizontal Beam-with |
10 Deg |
FBR | Greater than 25 dB |
Impedance |
50 Ohm |
Antenna Design |
48(6x8) Patch Array |
Internal Material |
FR4(Taiwan) |
Connector |
N-Female |
Length x Width(MAX) |
310 x 310mm |
---|---|
Diameter (MAX) |
30mm |
Antenna Weight (G.W) |
700 g |
Accessories (G.W) |
280 g |
Application | Indoor / Outdoor |
Radome Material |
White ABS |
Mount Style | Pole Mount |
Parts Material |
Aluminum |
Mounting | Stainless Steel and Aluminum |
Mount Adjustment | 0-30deg |
Wind Survival |
Greater then 120MPH |
Storage Temperature | -40 to +80 |
Operating Temperature | -40 to +60 |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity |
5%~90% non-condensing |
Safety, Emission and other |
CE, FCC, RoHS |
