Description
-
Electrical Specs
-
Mechanical Specs
Application
- 900MHz to 930MHz Band (Lora US915)
- US915, Lora Antenna
- Omni Directional Multipoint applications
- Point to Point Bridge / MMDS / Hotspot
- Public Wireless
- LoRa helium hotspot
Feature
- Superior Performance
- Good design
- DC Short lightning protection
- Outdoor antenna for public
- RoHS Compliant
|
Frequency Range |
900 MHz to 930 MHz |
|
V.S.W.R (avg) |
1.5:1 |
|
Antenna Type |
Collinear |
|
Gain (Max) |
12dBi |
|
Polarization |
Vertical |
|
Maximum Power |
50 Watts |
|
Vertical Beamwidth |
7 Deg |
|
Horizontal Beamwidth |
360 Deg |
|
Impedance |
50 Ohm |
|
Antenna Design |
Dipole Array |
|
Connector |
N-Female |
|
Dimension (LxWxH) |
2235x70x50mm |
|
Antenna Weight |
1.5kg |
|
Application |
Indoor / Outdoor |
|
Radom Material |
White Fiberglass |
|
Parts Material |
Aluminum |
|
Wind Survival |
Greater than 150MPH |
|
Storage Temperature |
-40 to +80 |
|
Operating Temperature |
-40 to +60 |
|
Operating Humidity |
10%~90% non-condensing |
|
Storage Humidity |
5%~90% non-condensing |
|
Safety, Emission and other |
RoHS |
